XPB-50 high pressure grouting pump
The fluid end of the pump adopts the assembly body and the transmission of the power end is the ball bearing with low noise and low temperature, which can keep working continuously for 24 hours.
XPB-50 high pressure grouting pump mainly applied for various grouting and oil well grouting. It is widely used pressure grout in tunnels, coal mine, bridges, dams, building foundation, and other underground projects.
Mobile Phone:
86-13939067523
E-mail:
dany@gaodetec.com
1. Low noise.
2. Can keep working continuously for 24 hours.
3. Simple maintenance and Long life.
4. Compact structure, light weight, small volume, beautiful appearance.
2. Can keep working continuously for 24 hours.
3. Simple maintenance and Long life.
4. Compact structure, light weight, small volume, beautiful appearance.
| Max.motor speed | 1300r/min | Plunger No. | 3pc |
| Plunger stroke | 110mm | ||
|
Motor power:55kw |
|||
| Plunger diameter | 55mm | 45mm | 40mm |
| Rated working pressure | 20Mpa | 30Mpa | 38Mpa |
| Theoretical output | 140L/min | 94L/min | 74L/min |
It is mainly used for ground and underground engineering construction, such as roads, railways, hydropower, construction, and mines.
Building structure
Building and bridge repair, foundation reinforcement, slope support, soil compaction, rock grouting..
Civil engineering
Dam, tunnel, subway, mine, soil nailing wall, curtain. Anchor, cable trench and anchor grouting.
Engineering
Underwater foundation, offshore platform, coast foundation grouting reinforcement.
Mine application
Roadway reinforcement, backfill, waterproof grouting. Acted as a grouting plant in the Pipe Jacking Machine.
